Part Number: POS MU00S1 | Fitment: Porsche 911 991.1 & 991.2 — Carrera 4, Targa 4, Turbo variants
Over 40 years of motorsport engineering distilled into a street-ready coilover kit. The Öhlins Road & Track series delivers a genuine racing experience without sacrificing daily drivability — thanks to Öhlins' proprietary Dual Flow Valve (DFV) technology. Featuring a McPherson front strut and conventional rear shock with a 10–20mm lowering range. Springs are included with our kit. Corrosion-tested to ISO 9227 and backed by a 2-year limited warranty.
⚠️ Note: Front length adjuster (06245-04) must be ordered separately for all models.
⚠️ Note: For vehicles equipped OE with PASM (Porsche Active Suspension Management), an Öhlins cancellation kit is also required (sold separately). See cancellation kit table below.
Vehicle Fitment — Porsche 911 991.1 & 991.2 (AWD Models)
Porsche 911 Carrera 4 |
991.1 & 991.2 |
Porsche 911 Carrera 4S |
991.1 & 991.2 |
Porsche 911 Carrera 4 GTS |
991.1 & 991.2 |
Porsche 911 Carrera 4 Cabriolet |
991.1 & 991.2 |
Porsche 911 Carrera 4S Cabriolet |
991.1 & 991.2 |
Porsche 911 Carrera 4 GTS Cabriolet |
991.1 & 991.2 |
Porsche 911 Targa 4 |
991.1 & 991.2 |
Porsche 911 Targa 4S |
991.1 & 991.2 |
Porsche 911 Targa 4 GTS |
991.1 & 991.2 |
Porsche 911 Turbo |
991.1 & 991.2 |
Porsche 911 Turbo S |
991.1 & 991.2 |
Porsche 911 Turbo Cabriolet |
991.1 & 991.2 |
Porsche 911 Turbo S Cabriolet |
991.1 & 991.2 |
Technical Specifications
Part Number |
POS MU00S1 |
Technology |
DFV — Dual Flow Valve |
Front Damper Type |
McPherson strut |
Rear Damper Type |
Conventional shock absorber |
Damping Adjustment |
Single bleed adjuster (front & rear) |
Front Spring Rate |
70 N/mm (Part No. 48000-19) — included |
Rear Spring Rate |
140 N/mm (Part No. 48010-47) — included |
Lowering Range |
Approx. 10–20mm below standard (front & rear) |
Top Mounts |
Use with original top mounts (front & rear) |
Springs Included |
Yes — front & rear springs included |
Rebuildable |
Yes |
Corrosion Testing |
ISO 9227 salt spray tested |
Warranty |
2-year limited warranty |
Included Springs
Position
Part No
Spring Rate
Front |
48000-19 |
70 N/mm |
Rear |
48010-47 |
140 N/mm |
Additional Parts (ordered separately for all models)
Part No
Description
06245-04 |
Front length adjuster — Porsche 991 (2pc per car set) — required for all models |
PASM Cancellation Kit (if required)
For vehicles equipped OE with PASM (Porsche Active Suspension Management), an Öhlins cancellation kit must also be used. Ordered separately.
Part No
Description
35020-07 |
Cancellation kit PASM |
General Features
• DFV technology (Dual Flow Valve) — Öhlins' proprietary damping system
• Individual height adjustment — approx. 10–20mm below standard
• Single bleed adjuster — compression and rebound
• Rebuildable for custom tuning
• Corrosion salt spray tested (ISO 9227)
• 2-year limited warranty
• Front & rear springs included
Front Features
• McPherson strut
• Single bleed adjuster
• Height adjustable — approx. 10–20mm lower than standard
• Coil springs included (70 N/mm — Part No. 48000-19)
• Use with original top mounts
Rear Features
• Conventional shock absorber
• Single bleed adjuster
• Height adjustable — approx. 10–20mm lower than standard
• Coil springs included (140 N/mm — Part No. 48010-47)
• Use with original top mounts
What is DFV (Dual Flow Valve)?
DFV is Öhlins' proprietary damping technology that sets the Road & Track range apart from conventional coilovers. The dual flow valve provides consistent damping characteristics on both compression and rebound strokes — the damper fluid follows a consistent flow path in both directions. This means the wheel and tyre can rapidly return to the road surface after a bump, maximising grip and traction at all times.
Because DFV opens more quickly on minor road imperfections, ride comfort is surprisingly supple — more akin to an OEM strut than a typical coilover. Over undulating surfaces, the compliance of the R&T units allows the car to crest bumps and potholes while remaining stable and in control. Traction is always maintained at its optimum level.
Why Öhlins Road & Track?
• ✅ Over 40 years of motorsport engineering heritage — trusted by factory race teams worldwide
• ✅ DFV technology — genuine race-car response with OEM-level daily comfort
• ✅ Covers all 991.1 & 991.2 AWD variants — Carrera 4, Targa 4, Turbo & Turbo S
• ✅ Springs included — 70/140 N/mm front & rear, ready to fit
• ✅ Rebuildable, ISO 9227 corrosion-tested, 2-year limited warranty
