Moton Suspension  |  SKU: AST-250-100-61

MOTON Linear Racing Springs – 250 Series (250mm x 61mm ID) - 250/100/61

$250.00 AUD
Shipping calculated at checkout.

MASSIVE RANGE

Over 20,000 performance & automotive SKUs for European, JDM, American, Korean and more

NATIONWIDE FAST SHIPPING

Quick dispatch across Australia with reliable tracked delivery

AUSSIE SUPPORT & EXPERTISE

Local customer service and technical assistance from our team of enthusiasts

Moton Linear Racing Springs

Premium 250-Series Replacement Springs (61mm ID)

Engineered for professional motorsport, these 250mm length linear-rate springs provide the consistency required for high-level chassis tuning. Manufactured from high-tensile chrome silicone steel, they offer maximum travel with minimal weight, ensuring your Moton or AST coilovers perform at their peak.

Specifications for Part #AST-250-100-61
Open Length (Lo): 250 mm
Spring Rate (R): 100 N/mm
Inside Dia (Di): 61 mm
Block Length (Sn): 128 mm
Block Force (Fn): 12200 N
Usable Stroke (St): 122 mm
Lo Open Length (mm)
R Spring Rate (N/mm)
Di Inside Diameter (mm)
Sn Block Length (mm)
Fn Force at Block (N)
St Usable Stroke (mm)

Series Reference Chart:

Part Number Lo R Di Sn Fn St
AST-250-20-61 250 20 61 - - -
AST-250-25-61 250 25 61 84 4150 166
AST-250-30-61 250 30 61 90 4800 160
AST-250-35-61 250 35 61 94 5460 156
AST-250-40-61 250 40 61 93 6280 157
AST-250-45-61 250 45 61 101 6705 149
AST-250-50-61 250 50 61 102 7400 148
AST-250-55-61 250 55 61 103 8085 147
AST-250-60-61 250 60 61 104 8760 146
AST-250-65-61 250 65 61 115 8775 135
AST-250-70-61 250 70 61 118 9240 132
AST-250-75-61 250 75 61 120 9750 130
AST-250-80-61 250 80 61 123 10160 127
AST-250-85-61 250 85 61 117 11305 133
AST-250-90-61 250 90 61 120 11700 130
AST-250-95-61 250 95 61 124 11970 126
AST-250-100-61 250 100 61 128 12200 122
AST-250-110-61 250 110 61 126 13640 124
AST-250-120-61 250 120 61 126 14880 124
AST-250-130-61 250 130 61 135 14950 115
AST-250-140-61 250 140 61 145 14700 105
AST-250-150-61 250 150 61 137 16950 113
