Moton Suspension  |  SKU: AST-220-85-61

MOTON Linear Racing Springs – 220 Series (220mm x 61mm ID) - 220/85/61

$250.00 AUD
Shipping calculated at checkout.

MASSIVE RANGE

Over 20,000 performance & automotive SKUs for European, JDM, American, Korean and more

NATIONWIDE FAST SHIPPING

Quick dispatch across Australia with reliable tracked delivery

AUSSIE SUPPORT & EXPERTISE

Local customer service and technical assistance from our team of enthusiasts

Moton Linear Racing Springs

Premium 220-Series Replacement Springs (61mm ID)

Engineered for professional motorsport, these 220mm length linear-rate springs provide the consistency required for high-level chassis tuning. Manufactured from high-tensile chrome silicone steel, they offer maximum travel with minimal weight, ensuring your Moton or AST coilovers perform at their peak.

Specifications for Part #AST-220-85-61
Open Length (Lo): 220 mm
Spring Rate (R): 85 N/mm
Inside Dia (Di): 61 mm
Block Length (Sn): 108 mm
Block Force (Fn): 9520 N
Usable Stroke (St): 112 mm
Lo Open Length (mm)
R Spring Rate (N/mm)
Di Inside Diameter (mm)
Sn Block Length (mm)
Fn Force at Block (N)
St Usable Stroke (mm)

Series Reference Chart:

Part Number Lo R Di Sn Fn St
AST-220-20-61 220 20 61 - - -
AST-220-30-61 220 30 61 - - -
AST-220-40-61 220 40 61 84 5440 136
AST-220-45-61 220 45 61 84 6120 136
AST-220-50-61 220 50 61 85 6750 135
AST-220-55-61 220 55 61 94 6930 126
AST-220-60-61 220 60 61 96 7440 124
AST-220-65-61 220 65 61 97 7995 123
AST-220-70-61 220 70 61 100 8400 120
AST-220-75-61 220 75 61 102 8850 118
AST-220-80-61 220 80 61 105 9200 115
AST-220-85-61 220 85 61 108 9520 112
AST-220-90-61 220 90 61 103 10530 117
AST-220-100-61 220 100 61 110 11000 110
